The Tools and Methods Behind a Lighting Plot for Stage and Studio

Starting with a plot on paper

Every lighting job here begins with a plot, a scaled drawing that shows where each fixture hangs, what it is, how it is powered and which control channel it answers to. Before I draw anything I ask for the venue's section and plan, the trim height of the grid or truss, and the position of any screens, risers or backdrops. A plot made from guesses tends to be rewritten on the day, and the day is the most expensive time to rewrite anything.

I keep the drawing deliberately plain. Each position has a name, each fixture has a number, and a legend sits beside the plot so a rigger who has never met me can read it without a phone call. The same sheet then feeds the patch list, the power distribution plan and the focus notes, so one set of decisions is not retyped three times and allowed to drift apart.

• Scaled plan and section of the room
• Fixture schedule with channel and address
• Power and cable run notes on the same sheet

Choosing fixtures for the room, not the catalogue

Fixture choice follows the space and the camera, if there is one. A low studio ceiling rules out big moving heads with long throw, and a wide festival stage rules out a rig made only of small wash units. I usually split a design into a few jobs: key light on the performer, colour wash on the set, texture from beams or patterns, and a handful of practical sources the audience reads as part of the scene.

For studio shoots, colour quality matters more than raw output, because a camera shows a poor spectrum far more than an eye does. For live stages, output and reliable weatherproofing matter more. We hire in or use our own stock depending on the date and the budget, and I would rather specify a fewer number of fixtures that I know well than a long list I have never programmed.

Rigging checks that happen before the lights go up

Rigging is where the plot meets gravity, so it gets its own routine. Before anything is lifted, we confirm the weight each point can take, the condition of trusses, clamps and safety bonds, and the order in which the load will go in. Hannah Croft's schedule gives the rigging crew a clear window so the lighting is not squeezed in around sound and staging.

Each fixture is fitted with a secondary safety attachment, cables are dressed away from walkways, and the whole rig is walked through once it is in the air. Anything unusual, such as a tight trim or a fixture hung close to a sprinkler head, is written on the plot rather than left to memory. It is slow work done in a set order, and it is the part nobody in the audience will ever notice.

• Load ratings checked per hanging point
• Safety bonds on every hung fixture
• Walk-through of the rig once it is flown

Programming: building looks before the band arrives

Most of the creative work on a console happens before the performers are in the building. Using a visualiser and the patched plot, I build palettes for colour, position and beam shape, then stack them into cues. Working this way means the first hour on site is spent correcting reality against the plan, not writing a show from nothing while a band waits to soundcheck.

I keep the programming layered. Palettes hold the colours and positions, cues call the palettes, and a handful of fast busking pages sit separately for the moments a set changes unexpectedly. If a fixture is swapped on the day, I change one palette and every cue that uses it follows. It keeps the show tidy, and it keeps a replacement operator from needing a long handover.

Operating the show and the studio alike

Running a show asks for different habits from designing it. At a concert I follow the music and the performer, calling cues by ear and keeping a few safe looks ready if a song is changed. In a studio the operator works to a camera: exposure, colour temperature and shadows are checked on the monitors, and small adjustments are made between takes rather than during them.

In both settings I like to speak with the sound engineer and, in studios, the vision mixer before the doors open or the first take rolls. Haze affects how beams read and how microphones sit, and a bright lighting state can wash out a screen the camera is shooting. A short conversation early saves a long argument later.

• Haze levels agreed with sound and camera
• Monitor checks for colour and exposure
• Safe fallback looks saved for changes

Notes and records that make the next job easier

After the show I save the console file, mark any changes on the plot and write a short note of what worked and what did not. A venue we return to benefits from this directly, since the next plot starts from a drawing that already matches the room, not from the first sketch.

I also keep a modest log of fixtures that gave trouble and the reasons, whether a failing fan, a worn clamp or a cable that kept coming loose. None of this is glamorous. It is simply the routine that lets a small team approach the next festival, studio day or private party with fewer surprises and a clearer idea of what to bring.
